Compact Multi-Parameter Monitor
| Measured Parameter | Ecg, Temperature, Heart Rate, Nibp, Spo2 |
| Configuration | Compact |
| Patient Type | Infant, Pediatric, Adult |
| Applications | Intensive Care |
12.1 Color TFT Display: The high resolution (800×600 dpi) ensures that waveforms and parameters are clearly visible.
ECG, NIBP, and SpO2 are included in separate parameter modules to ensure precise readings.
Real-time Analysis: SpO2 pitch tone variation, ARR analysis, and drug dose calculation, in addition to S-T segment and ARR analysis.
Energy Saving Mode: Standby mode is a feature that conserves energy and suspends monitoring when necessary.
Data Storage: Internal memory enables the review of 3600s of full-disclosure waveforms; it can be expanded with an SD card.Specification – Details
Model: MGE-IM1
ECG Lead Mode – Five-lead (R, L, F, N, C)
ECG Lead Selection – I, II, III, avR, avL, avF, V
ECG Waveform – Three and seven channels are available for selection.
Gain Selection for ECG – 0.5mm/mV, 1mm/mV, and 2mm/mV
ECG Sweep Speed – 6.2mm/s, 12.5mm/s, 25mm/s, 50mm/s
Adult heart rate range is 15 to 300 beats per minute, while neonates and pediatrics have a heart rate range of 15 to 350 beats per minute.
ECG Accuracy – ±1bpm or ±1%S-T Segment Detection – Measurement Range: -2.0mV~+2.0mV
SPO2 Measurement Range – 0~100%SPO2 Accuracy – ±2% (70-100%)Pulse Rate Range: 20 to 300 beats per minuteNIBP Method – Digital Automatic OscillometricNIBP Measurement Range – Adult: 40~270mmHg; Pediatric: 40~220mmHg; Neonate: 40~135mmHg NIBP Accuracy – ±2%
Thoracic Impedance – Respiration MethodThe temperature measurement range is 5 to 50°C (41 to 122°F), and the temperature accuracy is ±0.1°C. The respiration measurement range is 7 to 120rpm for adults and 7 to 150rpm for neonates and pediatrics.Recorder – Built-in, thermal array, recording width: 50mmAC 100-240V, 50/60Hz power supply
