Portable Patient Monitor

Reference: 1098788Monitoring
Other CharacteristicsContinuous, Plug-In Module, Mri-Compatible
Measured Parameter12-Lead Ecg, Resp, Temp, Heart Rate, Ibp, Abpm, Eeg, Emg, Spo2
ConfigurationPortable, Tabletop, Implantable
ApplicationsVeterinary, Intensive Care, For Mri, Clinical, Emergency, Ambulatory, Transport, Anesthesia, For Cardiology, Physiology, Neurology, Home Care
Patient ConditionFor High Blood Pressure, Copd
TechnologyPulse Wave Analysis, Electrical Impedance Tomography, Doppler, Ptt, Abi, Tbi, Finger Pressure
Options And AccessoriesWith Touchscreen, Wireless, With Built-In Printer, With Patient Data Management System, With Diagnosis Software
request_quote Request product information Back to catalog

Associated tags

TabletopImplantable12-Lead Ecg
manage_search

Product fit review

Compare the available product information with your application and purchasing requirements.

description

Documentation request

Ask which specifications, manuals, or commercial documents are available for review.

support_agent

Supplier coordination

Discuss quantity, destination, packaging, and timing before confirming suitability.

support_agent Request info description

Product information

Product summary

DTSF-12A Patient Monitor SpecificationFunction: ECG, RESP, TEMP, NIBP, SPO2, and PR

Optional: Dual IBP, CO2, CSM, GAS, and Recorder Display: 12.1 inches TFT  Touchscreen: optional Digital SpO2 with exceptional performance Characteristic human voice alarm Twelve hours of all waveforms and 720 hours of trend data Wireless and wired networks English, French, and Spanish comprise 16 languages.

 Russian, Portuguese, Spanish, German, and so forthECG is electrocardiogram.Lead modeFive leads: I, II, III, AVR, AVL, AVF, and V.

Increase0.25, 0.5, 1, and 2Heart rateAdult: 15 to 300 beats per minuteNeonatal/pediatric: 15 to 350 beats per minuteprecision ±1%

1 bpm resolutionSensitivity exceeds 200 μV P-PCMRR



Differential input impedance > 5 M ohmDiagnostic Mode Exceeds 90 decibelsMonitor Mode: >110 dB Surgery Mode: >110 dB

Current offset potential: ±300 mV

Leakage Current is less than 10 μA.PACE pulse detectionwidth: ±2 to ±700 millivolts

0.1 ms to 2 ms widthrise time: 10 to 100 µs PACE pulse rejection: 10 to 100 µswidth: ±2 to ±700 millivolts

width: 0.1 to 2 ms rise time: 10 to 100 µsBaseline recovery is less than three seconds following defibrillation.

Signal Range: ±5 mV p-p; Bandwidth:

Surgery 1 operates at a frequency of 20 Hz.Monitor: 0.5 to 40 Hz Diagnostic: 0.05 to 130 Hz

Calibration Signa1 mV p-p, -±5% accuracy ST measurementrange: -2.0 to +2.0 mVAccuracy -0.8mV to +0.8mV: ±0.02mV or ±10%, whichever is greaterNigerian Institute of Business and Politics

Measure and Alarm Range Pulse Rate Range: 40 to 240 bpmAdult ModeSYS 40 ~ 280 mmHg

DIA 10 ~ 220 mmHg

MEAN 20 ~ 240 mmHgPediatric ModeSYS 40 ~ 220 mmHg

DIA 10 ~ 160 mmHg

MEAN 20 ~ 170 mmHgNeonatal Mode

SYS 35 ~ 135 mmHg

DIA 10 ~ 100 mmHg

MEAN 20 ~ 110 mmHg

Static pressure accuracy is approximately 3 millimeters of mercury.Resolution: 1 mmHg Accuracy:

Maximum Mean Error: 5 mmHgThe maximum standard deviation is 8 mmHg.Overpressure Protection: Adult: 300 mmHg Pediatric: 240 mmHg

Neonatal blood pressure of 150 mmHg
