Portable Ultrasound System

Ophthalmology A/B Ultrasonic Diagnostic Systeminput:
output:For the purpose of conducting an ophthalmic ultrasound examination on humansDigital imaging technologyinput:
output:The image is delicate and clear, with a 12.1″ high-resolution color LCD display.A robust computer management systeminput:
output:Laser printers are supported by the built-in high-capacity hard disk, which also supports U-disc storage.Providing support for the DICOM interfaceinput:
output:Compact, user-friendly, and powerful designinput:
output:Integrated ultrasound image and medical record management systemObservation of double-image contrastinput:
output:Presenting five authoritative formulas, in which any two groups can be contrasted.SRK-T, SRK-Ⅱ, BINKHOST-Ⅱ, HOLLADAY, HOFFER-Q, any two formulas capable of calculating by contrast and displaying simultaneously.Performance:Ultrasound operating frequency: 10MHz (adjustable from 8.0 to 11.0MHz)Motor-driven sector scanning is the scan mode.input:
output:Gain adjustment: 0 to 50 decibelsinput:
output:TGC: eight-section modificationScanning angle: 53°Mode of display: B, B + B, B + A, Ainput:
output:Any measurement of areainput:
output:B – ultrasoundUltrasound operating frequency: 10MHz (adjustable from 8.0 to 11.0MHz)input:
output:Motor-driven sector scanning is the scan mode.input:
output:Gain adjustment: 0 to 50 decibelsinput:
output:TGC: eight-section modificationMode of display: B, B + B, B + A, Ainput:
output:Ten-level adjustable display depth: 20mm to 65mm (20mm, 25mm, 30mm,……, 55mm, 60mm, 65mm)input:
output:The scanning angle is 53 degrees.Resolution: Axial ≤ 0.2mm, Lateral ≤ 0.4mminput:
output:Accuracy of geometric position: Longitudinal ≤ 5%, lateral ≤ 10%input:
output:Grayscale: 256input:
output:DSC capacity: 640 * 512 * 8 bitsinput:
output:Image preprocessing: line averaging and frame averaginginput:
output:Image post-treatment: four categories of post-treatment curves (linear, logarithmic, exponential, and S-type)input:
output:Dynamic playback: cyclic or single playback, 25.6s/256
