Remote-Controlled Ophthalmic Chart Projector

The most prominent brand in the world.UNICOS is the first company in Korea to develop an auto chart projector. It has accumulated the most accumulated production experience and the most advanced technology, which has been demonstrated in the global market.The light source being used is an LED.

LED light source with a semi-permanent lifetime, which boasts increased brightness and clarityinput:
output:Clearly defined and precise projection chart
Clear and bright images are displayed on four distinct types of charts for the right vision test.Operation that is comfortable

The operator is stable and comfortable due to the rapid chart change and remote controller.Innovation design

Downsizing (30% reduction in comparison to ACP-700)
Lightweight (3.44kg, 27% lighter than ACP-700)Features That Stand Out

- The initial development to incorporate the most advanced technology and accumulated production experience

- A projection chart that is both precise and lucid- ACP-900 with 41 charts: A variety of charts

Design that is visually appealing- Fast chart changes and comfortable operation via remote control

- Chart types that are both versatile and diverseSpecification41 pieces of chartAverage Selection Speed: 0.3 seconds Mask One open, three vertical, three horizontal, and twenty-one single letters

Red/Green Filter

Proj. Distance: 2.0 to 7.0 meters (3 meters is the standard).Projected Magnification: 30 times (at a distance of 5 meters)Projected dimensions are ø 252 mm and 330(W) X 225(H) at a height of 5 meters.Ball Joint Tilt Angle (±10°)Lamp with LED technologyAC 100~240V, 50/60 Hz power supply 80 VA power consumption

Auto-Off Function: 5 to 10 minutes after

Body Dimensions/Weight: 165.7(H) x 188(W) x 300(D) / 3.44 KgRemote Controller: 20(H) x 64(W) x 195(D) mm/180g

Interface 8-pin connector for the control of the chart, mask, and R/G filter by a digitalized refractor's controller.Accessories: Dust cover, polarized metal screen, polarized glass, spare fuse, batteries, and spare lamp.
