Optotype Chart Monitor

The diverse selection of Huvitz LCD charts

The Optotypes System HDC-9000N/PF is now available in Full HD technology.input:
output:1. 24" LCD Chart with High Resolutioninput:
output:This 24 Color TFT-LCD Polarized Panel offers a chart with a resolution of 1920 x 1080 pixels.input:
output:2. A Wide Range of Standard Visual Acuity Chartsinput:
output:The HDC-9100N/PF supports a wide range of visual acuity and visual function tests with over 100 different charts.

Tests such as the Letter, Number, Landolt C, Snellen E, and Children chart, as well as other specialty charts, are included in standard charts.input:
output:3. Color Vision TestThe HDC-9100N/PF includes 12 charts for the assessment of color blindness and 9 charts for the classification of visual impairments.input:
output:4. Contrast Sensitivity TestThe HDC-9100N/PF also includes a feature that allows for the measurement of contrast sensitivity at different levels by utilizing letter charts and the bar. The patient is provided with additional information and a professional and analytical diagnosis as the results of the tests are analyzed and displayed.5. Hue TestThe HDC-9100N/PF supports the professional test, which consists of 85 color charts diversified by wavelength, and the simple test, which consists of 15 color charts, for the color blindness test.Specificationsinput:
output:LCD Type N-Type (Non-Polarized Panel): 24 inch Full HD TFT LCD PF-Type (Polarized Panel): 24 inch Full HD TFT LCD1920 x 1080 pixels is the resolution.

white luminance 250 cd/m²

Chart Window Size 24 inch: 531.4 mm (H) x 298.9 mm (V)

Power Input: AC100-240V, 50/60Hz DC+12V, 7.08A output

Data transmission is connected to a PC via USB and to an HDR/CDR via CAN.

Power Consumption of the Adapter: 100-250 V, 1.5-0.75 A, 50-60 HzProduct Power Consumption: 12 V DC, 4 A

Weight/Size of the Main Body 568 mm (W) x 336 mm (H) x 80 mm (D) / 6.1 kg
