Veterinary Ventilator
| Ventilation Mode | Non-Invasive |
| Applications | Veterinary |
| Type | Electronic |
| Configuration | Portable |
The Avante Volumax VOS is intended to introduce warm moisture into respiratory gases during the process of ventilation. In a variety of care settings, this product is appropriate for use with both large and small animals.input:
output:Characteristics
Within five minutes, the patient circuit can be replaced, resulting in minimal downtime. It is both detachable and disposable.
Electronic flowmeters and controllers, as well as an integrated oxygen/air blender.
All internal sensors are self-calibrating and self-monitoring.
If the AC power is interrupted, the internal battery backup ensures that the flow and oxygen percentage are maintained for a minimum of 15 minutes.
A single setting control knob on the front panel is used to adjust the oxygen percentage, flow, and temperature.
The maximum flow setting is automatically reduced if a low-flow cartridge is installed, as it automatically detects the cartridge type.
All values and alarms are displayed on a large, easily readable panel.SPECIFICATIONSDimensions:
Height: 11.5 inches
8 inches in width
7 inches of depth
Weight: 10.6 poundsinput:
output:In general,
Circulating Water Volume: Approximately 400 ml, which includes the delivery tube and cartridge.Installation: The rear-mounted clamp is compatible with IV poles with a diameter of up to 1.5 inches.Gas Connections: Standard DISS non-interchangeable fittings for medical oxygen and air.
Power: 100-240VAC, 50-60Hz, approximately 200VA during warm-up, approximately 80VA in steady state (dependent on temperature and flow rate)Backup Power: Four 4.8V nickel-metal hydride AA batteries.Gas Supply: Medical oxygen and air at inlet pressures ranging from 4 to 85 psi (28-586 KPa)Water: Sterile water in a sealed container that has been pre-filled.The duration of the warm-up is less than five minutes.The device is compatible with a wide range of care environments due to its universal power requirements.
