Resp Patient Monitor

● Application:It is capable of monitoring a variety of parameters, including ECG, respiration, body temperature, blood oxygen, non-invasive blood pressure, and end-tidal carbon dioxide. It is appropriate for newborns, children, and adults.input:
output:● Parameter:1. 12.1-inch color ISP display with a resolution of 1280*800

2. The weight of the instrument must not exceed 3.25 kilograms.

3. 5000 alarm event storage that allows for the analysis of long-term monitoring trends in a calm manner.

4. 4,000 pieces of blood pressure data, with a variety of screening methods for expedited browsing.

5. The end-tidal CO2 measurement range is 0-190mmHg, and the awRR measurement range is 0-150rpm.input:
output:● Benefits:1. The instrument’s boot time must be less than 10 seconds.

2. The 13CM extra-long double-sided alarm lights are 360° visible, making it easier to observe the alarm status.

3. In order to safeguard the safety of patients, the STAT measurement mode will automatically terminate after five minutes of continuous measurement.4. Provide support for a variety of interfaces, including the standard interface, list interface, trend coexistence interface, large font interface, full-screen 7 guide interface, and other interfaces.
