Oxygen Pressure Regulator

These precision pressure regulators are suitable for a variety of applications. They persuade due to their small size, high flow rates, and high accuracy. Their modular design enables a configuration that is cost-effective. A long lifespan is guaranteed by the high reliability and maintenance-free operation. An adjusting screw is employed to establish the pressure. Water can be utilized with pressure regulator versions that lack bleeder ports. These pressure regulators are constructed with a brass housing that is exceedingly durable. The inner thread of 1/8″ NPTF is utilized to establish the connection. Upon request, all pressure regulators can be configured to operate at a specific output pressure or at varying pressure levels. Seals may be converted from NBR to EPDM or Viton (FKM). Consequently, it is effortless to modify the regulators to accommodate unique media, such as oxygen (O2) or drinking water (H2O).input:
output:Upper limit of pressure: 0.75 bar

Pneumatic connection type: NPTF 1/8″Pressure range: 0 to 6 barVentilation without secondary exhaustMedium – media that is not aggressive

Returning mechanism – SpringAmbient Temperature: -0°C to +60°CHousing: brass galvanized, nickel-plated / plastic, seal: NBR, fabric-reinforced
