Zero Air Generator
| Configuration | Stackable |
| Applications | For Gas Chromatography |
| Gas Type | Compressed Air, Zero Air, Humidity |
| Technology | Psa, Catalytic Reactor |
| Other Characteristics | With Touch Screen |
The hydrocarbons are completely removed by the Platinum Palladium HC system (HCT < 0.1 ppm).input:
output:For a base line that is completely stable and noise-free, this is an exceptional choice for NPD and FID.input:
output:Modified to accommodate up to eight FIDsinput:
output:Prepared to establish a connection with the designatedAirComp compressorinput:
output:Up to four stackable tower configuration generators may be connected in parallel.The CPU is equipped with a touch screen display and can be connected to the generators via CAN-BUS.input:
output:allows for the monitoring of the operating status and menu reading with the maintenancestatus, the alarm report, and functional parametersinput:
output:Specifications of technical natureinput:
output:FLOW RATE – 3000 NmL/min ± 10% at a 2000 m SLM TECHNOLOGIES USED – PSA CLAIND + catalytic reactor Pl/Pdinput:
output:PURITY – HCT < 0.1 ppminput:
output:MOISTURE – ATP ± 2°C dew-point < -50°C ATPinput:
output:AIR INPUT CHARACTERISTICS – Particulate matter must be less than 0.01 mm.Oil Vapors ≤ 0.01 mg/m3input:
output:Dew point ATP: Moisture ≤ 3°Cinput:
output:Minimum pressure: 8 bar/115 psiinput:
output:Air flow rate: 8 Nl/minELECTRICAL SUPPLY – 250W, 115 Vac ±10%, 60 Hz250 W; 230 Vac ±10%; 50 HzINDEX OF PROTECTION – IP20NOISE – < 50 dBA for the 98% of the operation time < 60 dBA for 2 seconds each cycle OPERATING TEMPERATURE – 5°C to 35°C (41°F to 95°F)input:
output:ENVIRONMENTAL HUMIDITY – maximum of 90% without condensationMAXIMUM ALTITUDE – 2000 m slm DIMENSIONS – Height: 40 cm + 7 cm/15.8” + 2.8”Width: 38 cm/14.9″WEIGHT – 28 kg/62 lbs Depth: 53 cm/20.8″PNEUMATIC CONNECTIONS – Compressed air inlet: G 1/8″ femaleG 1/8″ female purified air output
