X-Ray Personal Dosimeter

Thermo EPD® Mk2 Personal DosemeterClicking on the image will cause it to enlarge.Thermo EPD Personal DosemeterHp(10) and Hp(0.07) readouts of gamma, beta, and X-radiation with an electronic personal dosemeterA multifunctional personal radiation monitor that is highly sophisticated and suitable for use in radiotherapy, nuclear medicine, and X-ray diagnosticsPIN diode detector: Contemporary detector technologyMeasures Hp(10) and Hp(0.07) in accordance with the International Commission on Radiological Protection (ICRP).External readers are capable of programming.Different visual and audible alarms can be configured.The software EasyEPD2 is included with all readers.Sv and rem are the units of display.Dose indication range: 0 μSv to 16 SvDose measuring range: 10 μSv... 10 SvThe dose rate range for dose measurement is 0 μSv/h to 4 Sv/h.Display resolution: 1 μSvGamma and X-ray energy range: 15 keV to 10 MeV, while beta energy range is 250 keV to 1.5 MeV.Programmable dose alarm thresholds: 2 x Hp(10) and 1 x Hp(0.07) valuesProgrammable dose rate alarm threshold: 2 x Hp(10) and 1 x Hp(0.07) valuesPower supply: One AA battery, alkal. 1.5 V or 3.6 V LTAcoustic alarm: approximately 98 decibels (A) at a 20-centimeter distanceDimensions: 85 mm x 63 mm x 19 mmWeight (including battery): approximately 95 g (with clip)
