X-Ray Inspection System

A single system that combines 2D X-ray electronics inspection technology with a 3D Computed Tomography (CT) option that is exceedingly user-friendly.Non-destructive testing that is suitable for beginners A 160 kV X-ray AXI system is utilized to ensure the productivity and profitability of electronic assemblies, components, and PCBAs through process and quality control.The Phoenix X|aminer is a user-friendly entry-level microfocus X-ray inspection (AXI) system from Waygate Technologies that is specifically designed to meet the unique requirements of high-resolution inspection of electronic assemblies, components, and PCBAs. It boasts robust performance. The system offers a significantly improved signal-to-noise ratio, sharpness, and life-imaging capability as a result of the new combination of CsI flat panel detector and computed tomography (CT). The Phoenix X|act base software for 2D and Phoenix Datos|x base for CT are proprietary and powerful software that facilitates both manual and automatic inspection.Key advantages of the Phoenix X|aminer include:A 160 kV / 20 W open X-ray tube with an unlimited lifetime is capable of penetrating even the most highly absorbing components.New detector with enhanced scintillator technology for enhanced electronics inspection quality.The comprehensive software package enables a simple and rapid computed tomography (CT) procedure.Phoenix X|act and Phoenix Datos|x provide intuitive operation.Flash! Electronics optimizes productivity by utilizing the most precise and rapid image processing.Real X-ray sample map that is automated for effortless orientation of samples on the top, bottom, and even inside
