Work Table

A novel necropsy concept that includes the potential for downdraft extraction and the ability to connect to an image and document management system (option).

To ensure that the user’s breathing zone is free of pollution.

For the purpose of pharmaceutical research, toxicology, or environmental research.

For the purpose of connecting to the in-house exhaust system.

Construction of a stainless steel frame that is self-supporting. Solid panels and body parts with double-walled insulation. The circumferential profile edge measures approximately 65mm.input:
output:
For optimal downdraft extraction of the gases, a three-part split perforated work surface (approximately 500x400mm) per side is equipped with finger holes and a rotating perforated edge (approximately 100mm wide).

Two servers are accommodated by a superstructure that includes two drawers and hinged doors.

With four spots for optimal illumination of the work area and lighting. The interior is fully wired, including data cables and outlets.

Inspection panels can be removed without the use of tools.

The station’s flexible exhaust outlet (180mm OD) can be directed to the ceiling, floor, or side wall.input:
output:Characteristics

A water mixer with a long nose and two sinks measuring 400 x 300 x 250 (D) mm.

Sink radii must be a minimum of 25mm to facilitate cleaning.

Two flex retractable hand showers, each with a 1600mm long tubing and two spray functions (soft and no spray), are located in the center of the working area.A surface that is positioned in a manner that allows for access to all points of the work surface.

Two sprinkler systems with spray nozzles are utilized to clean the area beneath the perforated work area. The center of the exhaust duct is a dome cover.

One storage board

Upper storage cabinet equipment:

Two server bays, each with exhaust slots above, are included. Two deposit shelves that can be adjusted in height, six 230V electric outlets, and one data cable opening.
