Wheelchair Lifting Platform

Installation of this solution is feasible:
in a private residence (to enhance the comfort of the home by making the rooms more accessible or facilitating the mobility of individuals with disabilities in wheelchairs)input:
output:
In a condominium, a platform lift can be used to resolve the classic situation of three or four steps in front of the ground floor entrance, which is common in the UK and Germany.input:
output:In order to address minor height discrepancies in a restaurant, office building, or shop.input:
output:
Platform lift measurements, encumbrances, and energy consumption values are also referred to as a vertical platform for the disabled, a lift, and an open shaft lift.input:
output:Installation

The system can be installed in three distinct configurations, both indoors and outdoors:input:
output:Standing alone

Masonry shaft

Steel-protected shaft

Load capacity: up to 400 kginput:
output:Distance: 2.99 meters or 2 stopsinput:
output:
Drive mechanism: worm screw and electric motorinput:
output:Velocity:0.05 m/s (Versions 1.100, 1.600, 2.100)0.10 m/s (Versions 2.600, 2.990)

Power supply and motor: The motor is situated within the shaft and has the following specifications:input:
output:Power rating: 2.2 kW; single phase for versions 1.100, 1.600, and 2.100; three phase for versions 2.600 and 2.990;AC – 50Hz single phase, line voltage: 230V ± 5%;
Voltage of the auxiliary power supply is 24 volts DC.
Supply of electricity Inverter-equipped motor (optional for versions 1.100, 1.600, and 2.100)input:
output: Files To be selected by the customer:Pre-walled anchoring brackets, or alternatively,mechanical anchors mounted on the rear wall

rear-wall mounted using chemical or hollow wall anchors

with a metallic support structure or protection

Rails that serve as guidesinput:
output:Constructed from T70-1A section that has been processed.
