Wet Granulator

Alexanderwerk manufactures the MG 100, a moist granulator that is specifically engineered to satisfy the specifications and standards of the pharmaceutical and chemical sectors. It is designed to produce granules with specific diameters from moist or pasty materials. The throughput can reach as high as 500 kg/h, contingent upon the raw material and cylinder perforation.input:
output:Bores for granulating cylinders are available in the range of 1.0 to 8.0 mm. The counter-rotating pressure cylinder is profiled (knurled) to improve the feed characteristics. The MG 100 is offered in a mobile design that offers exceptional flexibility during the granulation process. Maintenance and cleaning are effortless with all units' rapid disassembly.input:
output:TECHNICAL INFORMATION
Continuous operation with a throughput of up to 500 kg/hThe granulation cylinder has a diameter of 110 mm, while the pressure cylinder has a diameter of 90 mm. The holes in the granulation cylinder have a diameter of 1.0 mm to 8.0 mm.The working/operational length is 160 mm, and the weight is approximately 420 kg.

dimensions (HxWxD) - approximately 1,120 mm x 1,380 mm x 500 mm
