Veterinary Ventilator

This new Respirator, which completes the renowned Ugo Basile Ventilator line, boasts the following features:input: -
output:• The tidal volume, which is adjustable between 0.1 and 1 ml (or 0.05 and 0.5 with the smaller piston installed), can be selected using the knob while the pump is operating or at a standstill. The stroke volume scale is generously sized and features precise engraved marks.input:
output:• A three-digit solid-state display indicates the rate, which is selected by a knob, and is defined as 60-300 strokes per minute.input:
output:
• The air flow is effectively manipulated by appropriate channels and ports, resulting in virtually no dead space.



• The piston is operated by a distinctive variable stroke linkage mechanism.input:
output:Rods and articulated joints are the sole means by which the reciprocating motion is adjusted and transmitted to the piston. This results in minimal wear, no backlash, silent operation, and precise stroke reproducibility.input:
output:The instrument is self-contained, encompassing its power supply, which supplies the geared motor, feedback controller, and rate display. It is compact and lightweight, measuring 20 x 13 x 18.5 cm and weighing 2.5 Kg.



1. inhalation of air or another non-explosive gas mixture

2. the conveyance of air to the lungs of the animal3. Return the air from the animal.4. exhaust, for the purpose of sampling, partial recycling, and testing positive expiration pressure, among other things.So closely packed that the connection tubes are cut to varying lengths to facilitate the insertion of the tubing.
