Veterinary Ventilator

Veterinarians are required to input the animal’s weight, and the system will automatically match other parameters, including respiratory rate, tidal volume, and peak airway pressure, based on the standard ventilation parameters for dogs and cats.

R419 is capable of operating in both VCV and PIPCV modes. It offers veterinarians and animals more adaptable ventilation solutions.

Additionally, it features an exclusive APNEA mode. This mode is particularly well-suited for the wake period, as it does not impede the animal’s spontaneous breathing.input:
output:
Application: Teaching hospital, CT room, endoscopic operating room, and operating room.input:
output:Characteristics• Power supply that can be adjusted to operate at 110 or 220 volts• Portable and lightweight

• Offers intermittent positive pressure ventilation (IPPV) that is both safe and effective.• Offers internal battery power for a maximum of four hours.• Three modes: VCV, PIPCV, and APNEA

• It is equipped with two bellows of varying sizes: 20-300ml and 300-1500ml.• Respiratory rate (2-60 breaths per minute) Respiratory ratio (1:1.-1:1:4.0) Airway pressure rate: 5–35 cmH2OAdvantages1. A ventilation solution that is more adaptable, Allow veterinarians to determine whether to maintain the animal’s spontaneous breathing at the surgical stage or to select VCV or PIPCV based on the specific circumstances of the case.input:
output:2. The date input process is significantly faster than with traditional knob adjustments, and the human-computer interaction is more comfortable with touch-sensitive screens.input:
output:3. Reduce operational time and enhance user experience. Particularly for veterinarians who are not well-versed in ventilation parameters. They can effortlessly acquire mechanical ventilation skills by directly consulting the built-in data.
