Veterinary Radiography X-Ray Generator
Reference: 1156838
Radiology
| Options | With Power Supply |
| Type Of Imagery | For Veterinary Radiography |
| Ergonomic Design | Portable |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
Tube specifications (voltage/mAs): 50-90 kV/0.4-20 mAsAdjustment: 25 steps / 1 kVX-ray tube: OX/70 CEI
Focus: 1.2 x 1.2 mmCollimator: LED collimator with high luminosityDual laser and tape measure distance measurement
Operation: keyboard, 7-segment LED display, rotatable, 15 storage spaces for exposure values that can be freely programmed
100 kHz full-bridge inverter systemShutter release: two-area hand or foot release (remote control function for collimator light, kV, mAs)Battery serves as the power source.
Recording capacity in battery mode: approximately 560 images at 80 kV and 2 mAs.Weight: approximately 7.2 kgDimensions (in centimeters): 30 x 16 x 17Permanent filtration: 2.2 mm AI
Focus: 1.2 x 1.2 mmCollimator: LED collimator with high luminosityDual laser and tape measure distance measurement
Operation: keyboard, 7-segment LED display, rotatable, 15 storage spaces for exposure values that can be freely programmed
100 kHz full-bridge inverter systemShutter release: two-area hand or foot release (remote control function for collimator light, kV, mAs)Battery serves as the power source.
Recording capacity in battery mode: approximately 560 images at 80 kV and 2 mAs.Weight: approximately 7.2 kgDimensions (in centimeters): 30 x 16 x 17Permanent filtration: 2.2 mm AI
