Veterinary Radiography X-Ray Generator

The new 2.5kW Ultrapower 100 plus is a lightweight, high-power, and compact unit that is equally at home in surgery or on site.input:
output:The KV range is 30 to 100, with 2kV increments.A conventional 100mA is effective at a maximum high frequency of 40mA.

Prepared for disaster recovery. Plug your DR system in and proceed; no remote synchronization box is required.Built-in dual lasers that measure the distance and center of the beam. Consistently precise positioning

Clean the touch panel displays by wiping them.

kV, mAs, and time are displayed digitally.

Ensures output accuracy through automatic line voltage compensationSwitchable audible exposure warningFive preset memory functions are available.Powered by a 13-amp domestic supply.The total weight is 11 kilograms.

Compatible with any of our selection of stands and mountings.Five-year extended warrantykV (2kV steps) mA

40 mA (effective 100 mA) 32 to 60 kV35 mA (effective 87.5 mA) at 62 to 70 kV30 mA (effective 75 mA) at 72 to 80 kV25 mA (effective 62.5 mA) for 82 to 100 kV

Source: 240V, single-phase AC, 50/60Hz

Timer - 0.01 seconds to 2.00 secondsFocal point: 1.2mm x 1.2mmFiltration - 2.7mm Al equivalent

Dimensions: 240 mm in width, 360 mm in length, and 196 mm in height.Maximum weight: eleven kilograms
