Veterinary Poct Analyzer

The VP20 chemistry analyzer is compact and portable, requiring only a small amount of storage space. The system that is a "all-in-one solution" is easily operated. Additionally, veterinarians' requirements are accommodated through customized solutions. Additionally, distinct test panels may be implemented for distinct clinical applications.Assays:General Diagnostic Panel 16: TP, ALT, ALP, TBIL, CREA, UREA, CK, AMY, GLU, TCH, Ca, P, *GLO, *A/G, *UREA/CREKidney Diagnostic Panel 8: TP, ALB, CREA, UREA, Ca, P, tCO2, *UREA/CRELiver Diagnostic Panel 12: TP, ALB, ALT, AST, GGT, ALP, TBIL, DBIL, *GLO, *A/G, *IBIL, *ALT/AST Preoperative Panel 10: TP, ALT, AST, CREA, UREA, CK, GLU, LDH, *UREA/CRE, *ALT/AST Critical Care Panel 9: ALT, CREA, UREA, GLU, tCO2, K, Na, CL, *UREA/CREElectrolyte Panel 7: Ca, P, tCO2, K, Na, CL, MgSix test panels are included.
11 species are supported.Results in 12 minutes

Easy operation

Maintenance-free

Built-in printer and QR code scanner


…Principle: Microfluidics and colorimetrySamples include serum, plasma, and whole blood.Reaction time: 12 minutesSample volume: 140 ulVolume of diluent: 770 ulAnimals: Dog, cat, rabbit, mouse, pig, monkey, cow, sheep, lizard, horse, turtle, and sheepQR code: QR code scanner integrated into the deviceQR code that includes the disc type, time, items, and calibration curve

Wavelength: 340nm, 405nm, 470nm, 510nm, 546nm, 630nmSoftware upgrade: USB flash disk, WiFi support

Optical: LED lamp, with a lifespan exceeding 50,000 hours.Reaction temperature: 37℃±0.3℃Android 5.0 is the operating system.Storage: Up to 50,000 ResultsScreen: 7-inch touch screenPort: 1 LAN port, 1 USB-A port, and 1 USB-B portDimensions: 310mm x 250mm x 210mm (width x depth x height)Multilingual: English, Chinese, Spanish, Italian, Portuguese, Russian, and French
