Veterinary Intra-Oral Detector

Real-time diagnostics, direct USB plug-and-play connection, high definition, and immediate results are all embodied by the X-VS. NNT, the all-in-one software that is ideal for diagnostics, communication, and intraoral imaging management, is utilized by the X-VS. This software is capable of storing, managing, and printing images in perfect synchronization with any other device that is already present in the surgery.input:
output:Dual format

The X-VS is equipped with a sensor that is available in two sizes: ergonomic and with smoothed edges, which ensure exceptional positioning comfort by adapting to the anatomy of the patient's oral cavity. Advanced X-ray diagnosis is guaranteed by reduced dimensions and a maximum active area.input:
output:Sensor with five layers

High-contrast images and precise detail are achieved through the use of five-layer technology. Césium lodide (Csl) scintillator, which is composed of column-like microstructures, is designed to preserve image quality. It initially intercepts the X-ray beam and converts it into visible light. The layer of fiber opticsThe sensor is shielded from direct X-ray penetration by the fibre optic plate, which collimates the radiation onto it. The acquisition device, which is the third layer (CMOS HD), converts the light into a digital image with 16,384 grey levels. The image is pre-processed and converted into a USB signal by the fourth layer. The final layer serves as a protective layer.
