Veterinary Intra-Oral Detector

The EZ Dental Sensor is a CMOS area image sensor that was specifically designed for high-quality X-ray imaging. The image sensor is equipped with a monitoring photodiode that is responsible for the detection and monitoring of X-ray radiation. It has 2.1 mega pixels (1300×1700) with a pixel size of 20×20 μm. The FOP (fiber optic plate) utilized at the input window guarantees a long sensor life and high-quality image. This item is impervious to water and dust.input:
output:Primary Characteristics:• Pixel Dimensions: 20 x 20 μm

• Pixel Format: 1300 (H) x 1700 (V)

• 12 LP/mm High Resolution

• Dynamic Range: 57 decibels

• The interface is USB 2.0.• Supplied with a dose meter

• Dust and water-resistant, equivalent to IP67

• A single PC structure can be connected to three sensors simultaneously.

• Dimensions of the image (H x V): 26 x 34 mm• The total number of pixels is 1300 x 1706 (H x V).

• The number of effective pixels is 1300 x 1700.

• Type of scintillator: GOSinput:
output:Ratings and Characteristics:• Supply Voltage: 4.75–5.25 volts• Operating Temperature: 0 to 95 degrees Fahrenheit• Storage temperature in Fahrenheit: -4 to 158 degrees F• Incident X-ray energy: 20 to 90 kVp• Maximum current consumption is 155 mA.
