Veterinary Forceps

The veterinary ultrasonic soft tissue cutting surgical equipment is categorized into the following three components: 1. mainframe,2. transducer, 3. The ultrasonic scalpel blade, as illustrated in the schematic diagram below.input:
output:2. Introduction to Equipment2.1 Terminology and Diagramsinput:
output:1. Interface with the transducer2. Upper housing

–

3. Assembly of the tool bar4. Combo button with rubber coating -5. Torque wrench -6. Dial with a rubber coating7. Trigger with a rubber coatinginput:
output:8. Sleeve exterior

–

9. Inner sleeveinput:
output:10. Clampinput:
output:11. Tissue pad12. Terminal treatmentinput:
output:The blade comprises the transducer interface, upper shell, cutter arbor assembly, rubber-coated combo button, and torque wrench.The blade’s application portion comprises the treatment terminal, clamp, and rubber-coated dial wheel and trigger.input:
output:tissue pad, inner sleeve, and outer sleeve. The MAX button is located at the top of the manual switch, while the MIN button is located at the bottom. The MAX button’s default output is five levels and cannot be altered. The MIN button’s default value is level.3. The energy level is adjustable from level 1 to level 4.input:
output:2.2 Utilization of the Productinput:
output:1. The operator must obtain animal surgery qualifications in order to operate this product, which is exclusively intended for animal surgery.input:
output:2. This product is appropriate for the cutting of soft tissues in animals and can be employed to seal blood vessels with a diameter of no more than 3mm.input:
output:3. The JZCSD-200 host and JZCSD-P200 transducer series must be used in conjunction with this product.input:
output:2.3 Contraindications of the productinput:
output:1. This product and its accompanying instruments must not be used if the physician believes that ultrasound surgery may be inimical to the patient’s best interests.
