Veterinary Cr Scanner

Digitized X-ray with cassettes for veterinarians' standard X-ray examinations

The Divario CR-T2 is a CR desktop system designed for digital X-ray imaging in veterinary medicine. It has a maximum throughput of 73 cassettes per hour. The processing rate of the new Divario is 70% greater than that of older CR systems in high-speed mode (5 pixel/mm). The Divario is user-friendly, reduces the time required for animals and their owners to wait, and enhances the efficiency of examinations. The desktop system is compact, unobtrusive, and can be conveniently stored on any office shelf.

The compact and lightweight CR system offers a comprehensive suite of image processing tools when used in conjunction with the professional image acquisition software dicomPACS®DX-R. The solution is easily integrable into the workflow of a functioning clinic or research institution, for instance, to manage overflow and serve as a backup in an existing DR or CR system.input:
output:Available cassettes for the Divario CR-T2 include the following:IP cassette type CC:35 x 43 cm (14" x 17")

35 x 35 cm (14" x 14")

24 x 30 cm (10 x 12 inches)

18 x 24 cm (8 x 10 inches)

15 x 30 cm (6 x 12 inches)input:
output:IP cassette type LC: Long bone and full spine cassette(two cassettes measuring 35 cm x 43 cm or three cassettes measuring 24 cm x 30 cm are necessary.)

35 cm x 83 cm (14 inches x 33 inches)

35 x 124 cm (14" x 49") 24 x 30 cm (10 x 12 inches)input:
output:Benefits and Features of the Divario CR-T SystemSmall: Desktop unit with a compact footprint (0.30 m²)

Superior quality: High-quality images that are reproducible

Rapidly: The maximum processing capacity for an 18 x 24cm format is 73 cassettes per hour.

Flexible: Suitable for mobile use, portable
