Veterinary Anesthesia Evaporator

The Vapomatic™ Vaporizer is produced in the United States. It is a veterinary vaporizer of exceptional quality that is calibrated for specific agents and performs exceptionally well. It is compatible with the majority of anesthesia machines.input:
output:With over 40 years of experience in the design, testing, and servicing of all types and brands of vaporizers, this product was developed. The Vapomatic™ is engineered to deliver exceptional performance at low flow rates that are frequently employed in veterinary anesthesia.



■ Temperature compensated.
input:
output:■ The output concentration remains consistent during pressure pulses associated with assisted respiration.input:
output:■ A single unit that combines the filler, drain, and contents window for easy access.



■ The large dial features easy-to-read numbers and a "off" lock, as well as calibration indents.input:
output:■ Dial Rotation: CW to decrease and "off"; CCaW for "on" and increase.input:
output:■ The vaporizer's "Off" position is secured to prevent accidental activation.input:
output:■ When the switch is set to "Off," the vaporizing chamber is isolated and the gas is directed to the outlet.input:
output:■ Tamper-proof adjustments necessitate the breaking of the dial seal to gain access.input:
output:■ By removing a single screw, the sump can be removed for cleaning or wick replacement without affecting the calibration.■ The inlet and outlet fittings are individually replaceable and are standard 23mm male and female tapers. Additional connector alternatives are accessible upon request.input:
output:The rear mounting holes are interchangeable with those of other vaporizers.input:
output:The gas flow rate range is from 0.1 to 10 liters per minute.

Ambient temperature range: 60°F to 90°F.

Anesthetic concentration range: 0.5% vol.

Isoflurane or sevoflurane models are accessible.

Calibration accuracy: ±.1% concentration or ±10% of the dial setting at the calibration points.

Dry liquid capacity: Approximately 200 milliliters.

Dry weight: Approximately 7.5 pounds.
