Vacuum Thermoforming Machine

The Erkoform-3d+ exhibits identical attributes to the Erkoform-3dmotion, with the exception of an automated thermoforming process. Additionally, the touchpanel functions are identical. In order to facilitate a sudden formation, a substantial reserve vacuum is being maintained. The material’s precise temperature for thermoforming is guaranteed by a touchless temperature sensor, irrespective of the ambient temperature. The medium-wave infrared heating system of the unit does not necessitate any preheating time. The medium-wave enables the materials to heat up not only on the surface but also in the depths. The outcome is a splint that is less stressed.
The Occluform-3 is an accessory that can be installed.
Technical Specification
• H 31.5 cm / W 35 cm / D 37 cm• weight: 11.9 kilograms• foil diameter: 120 mm• foil thickness: 0 to 5.5 mm• 50-60 Hz, 220-240 volts (110-120) (100) volts• power: 340 watts• The maximum vacuum is 0.8 bar.• the noise level is less than 60 dB(A)• Program the foil, insert the foil, initiate the heating process, and position the model at the latest. The display provides a brief guide with animations that outlines the necessary working steps.
• No compressed air supply is necessary; simply plug and play.• No preheating is required.• A touchless temperature sensor that has been patented to accurately determine the actual temperature of the thermoforming material.
• A vacuum is created prior to the thermoforming process through sudden forming.
• Vertical pre-stretching and fitting to ensure consistent foil thicknesses.
• The unit can be operated with one hand to position the foil, which has a thickness ranging from 0 to 5.5 mm.
