Trolley-Mounted Veterinary Anesthesia Workstation

It is designed and constructed with the input of veterinary professionals from the outset.Features:



Features that are effortless to operate

The vaporizer and unit are designed to be seamless, allowing for effortless disinfection.

Precise Penlon vaporizers are capable of compensating for pressure, flow rate, and temperature.A compact unit that is capable of being mounted on a rolling stand and weighs only 40lbs.

Anesthetic agent output that is exceedingly precise

Switch easily between rebreathing and non-rebreathing circuits with a toggle switch.The oxygen flow rate is easily recorded by a basic gas pressure meter.

Flowmeter configuration: 0.1-4 liters per minuteVaporizer configuration: Isoflurane (Sevo Vaporizer also available on a POA basis)Oxygen flush flow rate: 30-50 L/min CO2 absorbent canister: <1000 ml 10-year service-free vaporizerStandard Accessories Includedinput:
output:Uni-limb Breathing CircuitCoaxial Breathing Circuit500ml, 1L, and 2L Rebreathing Bags

500g of soda lime Endotracheal tube rack Y connector (22mm) ET tubes and connectors (2.5–8.5mm) Set of six anesthetic breathing masks Technical specificationsSize



Width: 17.9 inches (46.5 cm)Height with Trolley: 50.6 inches / 128.5 cmHeight without Trolley: 17.1 inches (43.5 cm)Depth: 14.6 inches / 37 centimeters Weight:Without a trolley, the weight is 40.8 lbs (18.5 kg). With a trolley, the weight is 55.1 lbs (25.5 kg).Medical oxygen is supplied at a pressure of 400±50 kpa.input:
output:Configuration of Oxygen FlowmeterStandard: 0.1 to 4 liters per minuteOptional: 0.1 to 10 L/minVaporizer ConfigurationIsoflurane is the standard.Optional: SevofluraneVaporizer Output Range and AccuracyIsoflurane: 0.2 to 5%; precision: ±.2 volume percent or ±20% relativeSevoflurane:.2 to 8%; accuracy: ±.2 volume percent or ±20% relative
