Treatment Room

Casaluci Healthcare’s HEALTHSHELTER is the solution to promptly address medical emergencies.

A module that is designed to meet the most stringent medical standards, is incredibly simple and rapid to install, and is immediately operational due to the integrated electrical, gas, and air treatment systems.

HEALTHSHELTER is a modular ICU that is completely independent and can work in synergy with the existing hospital in the event of a serious medical emergency, when there is no time to construct new wards or hospitals.

HEALTHSHELTER by Casaluci Healthcare is a health care shelter that is also designed to be quickly dismantled at the conclusion of an emergency and stored in designated areas for future use.input:
output:
1. External framework composed of Corten steel.
2. Electrical, gas, and air treatment systems that are integrated.3. Window of control.

4. Doors made of hermetic stainless steel.input:
output:Negative pressure for air management.5. Mineral wool slabs for thermal insulation.

6. The light sources are of the LED variety.

7. Painted steel tiles with a hermetic ceiling.8. Horizontal BHU integration.

9. Stainless steel modular paneling with an antibacterial coating.

10. PVC floor soldered in a single piece with round skirting that is perfectly connected to the walls.input:
output:An independent air treatment system is implemented in each module, which ensures:• A minimum of 12 air changes per hour;• Negative pressure within the module (-15Pa);• Absolute HEPA 14 filters have been installed.input:
output:Each module is equipped with a pressure reduction panel that is independent for AIR, VACUUM, and OXYGEN. The panel is equipped with shut-off valves at the entrance and exit.

Two units are included for the alarm signalization: one is located within the module and the other is located outside. These units are classified as “clinical” and “emergency.”
