Tonometer

TonoVue-P is a single device that combines intraocular pressure (IOP) and central corneal thickness (CCT) measurements. TonoVue-P provides accurate measurement results for CCT, IOP, and compensated IOP by integrating the technologies of Scheimpflug camera, soft air puffing, and 3D auto tracking.



Operation that is entirely automated

Multiple IOP measurements can be performed with a single touch of the "start" soft key, thanks to fully automated 3D eye-tracking. input:
output:Automatic CCT Measurement

TonoVue-P has exceptional repeatability and accuracy in measuring CCT through the use of Scheimpflug technology.



Printer with automatic cutting capabilities

The TonoVue-P printer is equipped with an auto-cut function that prevents paper jams during printing.input:
output:Soft Air Puff

TonoVue-P provides a gentle and quiet air puff to ensure that patients are at ease. input:
output:10.1" LCD Touchscreen DisplayThe patients' database input, search, and display are all facilitated by the large touch screen, which also facilitates IOP measurement.input:
output:TonoVue-P model

Intraocular pressure Measurement range: 0.4-0.80 mm Light source: Blue LED1-60 mmHg measurement rangeSetting the measurement range: Auto, 30 mmHg, or 60 mmHg

Air puff method - Measurement principleIn units of mmHg/hpa, the display is performed.

Working distance: 11 millimetersAlignment - Completely automated 3D trackingMotorized chinrestDisplay: 10.1" LCD touch screenPrinter - Thermal printer with an automatic cutterInterface: RS232/USB

AC110V to 240V, 50/60Hz, auto-selected power supplyOperating Environment - Temperature: 10°C to 35°C,Humidity ranges from 30% to 90%.

Dimensions (WxDxH): 280 mm x 485 mm x 480 mmWeight: 17 kilograms
