Tms + Rtms Transcranial Magnetic Stimulator

The PowerMAG LAB 30 is the ideal entry point for time-sensitive TMS tasks due to its high-precision triggering and the ability to freely control all parameters using digital and analog signals. This device is a versatile stimulator for TMS labs, as it maintains a consistent output power for all protocols, including single pulse, rTMS, and trains.input:
output:Characteristics

no reduction in pulse intensity during stimulationhundred percent Intensity of up to 30 Hz *Complete external control

Available in both half-wave and full-wave configurations

By pressing the button, the coil’s current direction is reversed.* subject to the power supplyinput:
output:Maximum frequency: 30 Hz

Maximum frequency: 0.1 Hz

ISI minimal change value – 1 ms Minimal ISI – 33 msFrequency minimal change value: 0.1 Hz

Maximum frequency at 100% intensity: 30 Hz *Maximum Intensity: 100% (complete frequency range)Parameters of stimulationMagnetic induction – up to 4 tesla (subject to coil)160 Joules — maximum pulse power

Pulse shapes: Half and full sine-waveThe coil’s current direction is inverted on the equipment.The stimulation pulse’s rise time is 80 μs (PA).Pulse duration: 160 μsInterface for input and outputTrigger input: BNC-connector (TTL pulse, active high)Trigger output – BNC connector (active high, TTL pulse)External interface – 8-pole DIN connector (Custom stimulation protocols, TBS, ramp, single pulse, and repetitive mode are supported.)BNC connector for synchronizationQuality that is “Made in Germany”2000000 discharges at 100% intensityProtection class 1, Type BF – Electrical safety

Hardware classification in accordance with MDD 93/42/EEC – class IIaHardware certification: CE 0494
