Tissue Sample Slide Dryer

The Slide Dryer LSLD-A10 is a compact dryer unit designed for the purpose of drying paraffin tissue sections for mounting. The dryer's temperature is managed by a microprocessor. Thermal heaters are included to ensure uniform heat transfer. The temperature of the unit is adjusted and viewed using an LED display screen. It is optimally employed in the fields of biology, pathology, histology, and cytology for the purpose of mounting paraffin tissue sections.Specifications

Temperature range: RT to 90°C

temperature precision - ± 1 °C

0°C to 40°C environmental temperature range

340 mm x 325 mm drying area
LED display

Power consumption: 200 watts and above

Voltage - AC 220V ± 10%, 50/60 Hz

AC 110V ± 10%, 60 cycle

External dimensions (W × D × H): 360 × 350 × 120 mmPacking dimensions (W × D × H): 410 × 410 × 190 mmWeight: 6.2 kgCharacteristicsMicroprocessor controllerAutomatic memory and restoration functionsIntegrated temperature sensing blocks for temperature measurement. Surface material exhibits exceptional resistance to corrosion and abrasion.Protection from OverheatingTemperature visualization via LED display screenSimple to operate and modify.Applications br/>


Even heat transfer is guaranteed by thermal heaters.Drying and mounting paraffin tissue sections on slides is a common practice in histology, cytology, pathology, and biology laboratories in industrial and clinical lab settings.
