Tilting X-Ray Table

Rotation: from a vertical position of 0° to a vertical position of 90° in 22 secondsTredelburg is situated at a temperature of -25°.Automatic halt in the horizontal working position (0°)Table top dimensions: 2100 x 800 mm (excluding profiles, which are 2100 x 640 mm)Tabletop transversal length: 30 cm (+/- 15 cm)Tabletop longitudinal length: 100 cm (+/- 50 cm)

Minimum height of tabletop from floor:
- at the profile rails, 655 mm- 630 mm at the tabletop
Height of the table top from the floor in the working position: 1050 mm (at the profile rails)
The longitudinal length of the X-ray tube column is 160 cm.

The longitudinal length of the flat panel is 115 cm.The maximum speed of the column-flat panel is 15 cm/s. The distance between the focus and the film is 100 to 180 cm. The X-ray tube rotates automatically at a rate of 270° (-90° + 180°).Tomography Angles: 8° - 20° - 30° - 40°Tomography Times: 0.1 - 1.0 - 1.5 - 2.0 seconds.

Tomographic layer height: 1 mm to 350 mm.Grid



Encoumbrance LxD approximately 2100 x 1650 (with the tabletop in the central position)

The overall height is approximately 2400 cm, with the table top in a horizontal working position and the DFF at 100 cm.

Weight: approximately 1180 kg (including the flat panel) + 115 kg RACK
