Tibial Intramedullary Nail

Nite is a titanium nail that is specifically for the treatment of tibial fractures. Nite assists healthcare professionals in attaining superior operative and postoperative parameters by employing Claw technology for distal locking.input:
output:Nite’s fully cannulated body is compatible with guide-wire applications and provides a 7 mm compression range, which provides surgeons with additional resources during the operation.input:
output:Signs:● Intertrochanteric fractures● Stable and unstable pertrochanteric fractures● Shaft extension is not present in cases of high subtrochanteric fractures.

● Low subtrochanteric fractures (Neon Long Nails only)● Osteoporotic fractures

● Pathologic or impending pathologic fractures● Nonunions/malunionsThe key figures of Nail● Length of nails○ Neon Short: 220 mm○ Neon Long: 300 mm to 420 mm in 20 mm increments

● Proximal Diameter○ 15.5 mm● Distal Diameter○ 11 mm● Maximum Distal Claw Span: 38 mm● Lag Screw Angle

○ 120°, 125°, and 130°

● End Cap Length

○ 0 mm to 10 mm in a 5 mm increment○ Internal thread to secure the cap to the driver● Length

Key figures of Lag Screw○ 5 mm increments from 70 mm to 120 mm• 11 mm thread diameterThe compression range is 15 mm.● Maximum span of lag screw claw○ 28mm when fully deployed
