Thermal Printer

Cardinal's P150 mobile high-speed direct line thermal printer is powered by a rechargeable lithium-ion battery (included) and is designed for use with portable scales. The P150 boasts a long-life printing head and high reliability, while also being compact and robust. It boasts a paper drop-in style, a printing speed of 3.15 in/80 mm per second, a resolution of 203 DPI x 203 DPI, and serial and USB connectivity, which facilitates paper handling. The battery status is indicated by three LEDs. For a continuous use of 90 minutes, the charging time is 2 hours. The overall dimensions are 3.7 W x 5.3 D x 2.2 H inches (96 W x 136 D x 58 H mm). The print width is 1.89 in/48 mm, with a resolution of 384 dots. A standard serial printer cable is included.Features: 203 DPI x 203 DPI ResolutionLightweight and portable Long-lasting lithium-ion battery Paper drop-in style handlingPrinting at a speed of 80 mm/s RS232 serial and USB interfacesStandard Serial Printer Cable Included



Specifications

Direct line thermal printing is the method of printing.Printing Speed: A maximum of 3.15 inches or 80 millimeters per second.Resolution: 203 DPI x 203 DPIPrint Width: 1.89 in / 48 mm, 384 dotsCharacter: ALPHA NUMERIC Character, Extension CharacterFont: Font A (12 x 24 dot), Font B (9 x 17 dot)Number of Columns: 32 (Font A) and 42 (Font B)Barcode: EAN-8, EAN-13, CODE 39, ITF, UPC-A, Codabar, Code93, Code128, PDF417(2D)

Emulation: ESC/POSDriver: Windows CE 4.2&5.0, Windows Mobile 5.0Sensor: Paper End Sensor, Gap Sensor, Cover Open SensorPaper Type: ThermalPaper Width: 3.5 inches / 88 millimetersBattery: 90 minutes of continuous printing. Standby for 24 hours Communications: Wireless Lan 802.11b/g (CMP-20WF), USB, Serial (RS232C)Battery Charger Input: AC100-240V, 50/60 Hz Battery Charger Output: 8.4V, 1200 mABattery Type: Lithium Ion
