Temperature Controller

This microscope stage temperature control system guarantees precise and consistent thermal regulation of live biological specimen observations. It is designed to meet the user's stage warming requirements and is compatible with all biological microscope brands (or any other microscope upon request) and is particularly well-suited for the assessment of semen motility. The stage warming deck is constructed from high-tensile aluminum, which ensures a consistent temperature of less than +/-1° C within a temperature range of 20° C to 90° C. The desired temperature is achieved by preheating the stage for 1 to 5 minutes. While conducting an examination or analysis of sperm motility and velocity or other live biological specimens under a microscope, this stage warmer is optimally suited to maintain consistent specimen temperatures.input:
output:Specifications and Features:



Easy installation for any standard microscope stageinput:
output:Two LED digital displays and two pouch bottoms are located on the temperature controller.DC 12V / 5A power inputinput:
output:Power output: 60 wattsTemperature control range: 20º C to 90º CTemperature setting increments: 0.01º CTemperature display divisions: 0.1º Cinput:
output:Temperature varies between setting and displaying: less than +/-1º Cinput:
output:Stage warmer plate dimensions are as follows: 140 mm in width, 130 mm in length, and 8.5 mm in thickness.input:
output:The control unit's dimensions are as follows: W 160mm x L 130mm x H 48mm.Net weight: 0.450 kilograms
