Teaching Microscope

The Infinity Optical System (10S) is a single-molded modular stand that is corrosion-resistant and anti-fungus treated, with a C-shaped design.

30° Inclined Siedentopf Trinocular tube, 360° rotatable, IPD 48-75 mm with dioptric adjustment, and 30° Inclined Siedentopf Binocular tubes, 360° rotatable, IPD 48-75 mm with dioptric adjustment, 4 headsinput:
output:OPTIC SYSTEM -

Infinity Optical System (IOS)



STAND -

Single-molded, corrosion-resistant, and anti-fungus standVIEWING BODIES -30° inclined Siedentopf trinocular tube, 360° rotatable, IPD 48-75 mm with dioptric adjustment

Siedentopf binocular tubes with a 30° incline, 360° rotation, IPD of 48-75 mm, dioptric adjustment, and four heads.Eyes -


WF 10x/20mm with eye-guards (10 units) NOSEPIECE -Quintuple nosepiece with an inward tilt (reversed)OBJECTIVES -

Infinity Objectives, Semi Plan / Full Plan / Phase Plan Achromats4x/NA 0.10, 10x/NA 0.25, 40x/NA 0.65 SL, and 100x/NA 1.25 SL, oilMECHANICAL STAGE -185mm x 142mm double plate. 75mm x 55mm X-Y travelCONDENSER -Swing condenser with a daylight blue filter and an aspheric lens with a numerical aperture of 0.9/0.25.FOCUSING MODULE -Co-axial coarse and fine focusing system on ball bearing guide ways that is ergonomically designed for low positions. Unique Focus lock and tension adjustment ring are included.Illumination - External Koehler Illumination, 24V-nowHalogen Lamp, CE Compliant, Universal Power Supply 100 V to 240 V, AC 50-60 Hertz.POINTER -Adjustable brightness green electric pointer unitOPTIONAL ACCESSORIES -Flip Top Condenser, Phase Contrast Kit, Dark Field Kit, Green filter, Polarizing kit, Video adapter, Photo adapters for 35mm SLR camera, CCD camera, and digital still camera, and 10x Photo eyepiece.
