Surgical Camera

A medical-grade camera system with a fully integrated triaxial mount that is capable of capturing surgical proceedings in ultra-high definition.4K ultra-high definition resolution at 60 frames per second

Clear, close-up images are achieved through the use of a 30x optical zoom.

Integrated triaxial camera mount with the ability to pan, tilt, and roll

Simple operation is achieved through intuitive camera movement.

The camera head and CCU are connected by a single cable.

Even when the zoom is at its highest, the positioning remains

Connect to the ceiling arms to ensure that the video is not obstructed.4K Ultra-High Definition Resolution

The surgical field camera utilizes a progressive 60 Hz signal to capture images of the surgical site in 4K UHD resolution (3840 x 2160). This results in high-quality, smooth images.input:
output:Detailed Zoom into Narrow Target AreasCameras are capable of zooming into small target areas with an optical zoom of up to 30x. The camera can clearly zoom into and capture narrow surgical sites in detail, even when positioned at a safe distance.input:
output:Smooth Positioning at High Zoom

To prevent the field of view from moving too quickly, the camera’s pan, tilt, and roll movements slow down as it zooms in, utilizing a distinctive and intelligent stepping technology. The preparation for surgery is expedited and simplified by the ability to easily control movements, even under high zoom.input:
output:Camera mount that is fully integrated

The camera head is fully integrated into a camera mount that allows for a +/-170 degrees pan, +90 to -30 degrees tilt, and +/-165 degrees roll, ensuring that the field of view can be easily adjusted to the desired location.input:
output:Panning and tilting directions that are intuitive

The camera head is integrated with the camera mount, which enables left and right, as well as up and down movements, to remain parallel to the field of view, even after rolling.
