Supply Cabinet

The B series of StU storage cabinets are constructed from electrolytically galvanized and chromated thin sheet steel, with powder-coated surfaces. Selection of colors from the Becker Colour list. The technical cabinet details are consistent with those in our "Fitted Furnishings" Information brochure. The doors are equipped with chromium-nickel steel bridge handles, and the standard base height is 100 mm.

The cabinets are equipped with grid ledges that can be used to mount StU trays made of AISI 304 (1.4301) chromium-nickel steel. The cabinets are available in two widths: 750 mm and 1100 mm. Both sizes feature vertical partition walls. Each compartment has the capacity to accommodate up to 11 individual 1/2-StU containers. The vertical position can be individually adjusted in 25 mm increments. We also provide grid ledges and partition walls made of chromium-nickel steel at an additional cost. Additionally, these cabinets are accessible as furniture from the series V "chromium-nickel steel" collection.
Kindly specify the quantity of StU trays that you require.
