Straight Arthroscope

The Medacta MectaScope System is employed to conduct arthroscopic diagnostic procedures on human joints, including the knee, shoulder, and hip, from the inside. This system provides surgeons with high-definition images that have been magnified.input:
output:MectaScope arthroscopes generate magnified images by means of a circular field of view.

Two distinct configurations are accessible:input:
output:Red is the color code.

Equipped with a self-centering coupling system that prevents fluid leakageinput:
output:Code color: Yellow

Equipped with a self-centering coupling system that prevents fluid leakage



Adapters are included with the MectaScope to accommodate the majority of common light guides:LIGHT ADAPTERS

Wolf Cable Adapter

Storz-Olympus Cable Adapter
ACMI Cable Adapter: included in the scopeinput:
output:DESIGNATED INSTRUMENTSinput:
output:Rotating sheathThe sheath is employed to ensure visual clarity and continuous flow into the surgical site by maintaining the portal into the joint. The washing and cleaning process can be facilitated by the disassembly of the MectaScope - Rotating Sheath.input:
output:Sheath - Barrel Ø6mmCannulated with a diameter of 4mmFluid passage into the joint is facilitated by the fenestrated tip.Equipped with a self-centering coupling system that prevents fluid leakageSpigot plane - Sheath

Designed with valves to assist surgeons in the regulation of fluid inflow and outflowLiquid injection or suction through a Luer Lock connectionIn order to prevent tubing from twisting during the procedure, the spigot plane is permitted to rotate in relation to the sheath.
