Semi-Automatic Tray Sealer

Die-cutting mold

Atmospheric modification - MAPinput:
output:Our MIZAR Tray sealers machine is the optimal choice for the packaging of semi-processed or processed foods that contain sauces and liquids. The product's freshness is preserved while the expiration date is extended through the use of MAP modified atmosphere sealing and heat sealing. The tray profile undergoes customized die-cutting during the semi-automatic sealing process. MIZAR is the ideal choice for continuous and intense use due to its high functional efficiency and exceptional construction quality.



Optimal heat sealing

The primary function of a heat sealer is to adhere the film to the tray by means of heat. This is known as the top seal.input:
output:
Simple to open

The Easy Peel film sealing technology is designed to ensure that the opening process is always simple and intuitive.MAP - Protective Atmosphere

This technology utilizes the injection of filler gases to extend the product's shelf life and ensure its freshness.input:
output:The tray is perfectly cut.

The mold's meticulous construction ensures that the excess film waste is precisely cut, thereby ensuring that the product is of the highest quality.input:
output:The maximum size of a tray isinput:
output:The maximum area is 400 x 280 x H120 mm.For instance,No. 1 GN 1/2No. 2 GN 1/4Data sheet:ALUMINUM/STAINLESS STEEL machine structure

The maximum length of a film reel is 430 millimeters.The maximum tray size is 400x280 mm with a height of 120 mm.Die-cutting blades, automatic film cutting

Molds for interchangeable traysElectrical supply: 400 V, 50 Hz, 3P+N+T

Machine dimensions: L 510 x H 1350 x D 750 mm - 160.00 Kg

Becker 40 m3/h vacuum pumpSOFTWARE - TESMIT PKG 4.0Our customers are granted an unparalleled user experience as a result of our proprietary Tesmit software.
