Semi-Automatic Polarimeter

Range: ±90°/±130°Z

Optical rotation, specific rotation, concentration, and international sugar are the measurement parameters.Zero-point calibration modifiesEliminates the measurement error.One hundred datasetsinput:
output:
Optical rotation, specific rotation, concentration, and the international sugar scale (°Z)The following are the features:A semi-automatic polarimeter with a 5.6-inch TFT touch screen that is capable of multiple parameters;
The following four measurement functions are optional: optical rotation, specific rotation, concentration, and international Brix.A long-life LED that circumvents the 200-hour usage limit of conventional light sources;One key is required to restore the instrument's optical zero point through automatic zero reset.In an instant, the measured value is converted to the specific rotation value through automatic temperature compensation.Custom input or selectable tube length;1 to 3 point calibration to guarantee measurement accuracy throughout the entire range;Automatic information prompts are provided to assist users in comprehending the steps of the operation that are currently being executed.Data storage capacity is 100 sets, with the ability to input the sample name, date/time, and automatic marking.The meter's factory default settings are automatically restored by the reset function.SpecificationsRange: ±90°/±130°ZResolution: 0.005°Precision - ±0.02°/±0.05°ZCalibration Points: 1 to 3 points

Temperature Correction: 0°C to 50°CLight Source: LED and interference filter589 nm optical wavelengthSample tube length: up to 200mm100 data sets are stored in the data storage.

Interface for Communication: USB

Display: 5.6-inch TFT touch screen

Power Requirements: AC 220V/50HzInstrument Dimensions(L*W*H)(mm) - 550*300*220 mm Package Dimension…630*290*490mm (W*D*H) (mm)Net weight/gross weight (kg) - 7.5kg/9kg
