Round Air Diffuser

Long vertical throw length of up to 28 metersHigh-induction airstreamSuitable for rooms that are elevatedinput:
output:Available in five sizes, with connections ranging from 250 to 630 mm.Installation can be conducted directly on the duct or through the SKKU connection box. The throw direction can be continuously regulated from horizontal to vertical.Diffusion pattern control may be implemented manually or automatically.Vertical throw length that is extendedDetailed information regarding the product is provided below.The ODZA adjustable ceiling swirl diffuser is designed for commercial and industrial buildings with high ceiling interiors and a large room volume, such as market halls, warehouses, and factories. The diffuser's functionality can be customized to accommodate both summer and winter conditions. ODZA can be adjusted manually or with the assistance of a thermal element or electric actuator.input:
output:The ODZA adjustable ceiling swirl diffuser is designed for commercial and industrial buildings that have a high ceiling interior and a large room volume, such as market halls, warehouses, and factories.The diffuser's functionality can be customized to accommodate both summer and winter conditions. The atmosphereThe blades' angle is adjusted to regulate the diffusion pattern. The remaining blades are capable of rotation, while half of them are fixed. Upon completion of the movement, they make contact with the fixed blade sur-face.

Consequently, holes are generated and differentiated between the fixed and movable blades.

The fuser commences operation with the "nozzle" effect. As a result, it is capable of achieving an extremely long vertical throw.

The ODZA swirl diffuser has an air flow range of 39 to 2500 l/s (140 - 9 000 m3).

and has a height of installation that ranges from 3 to 28 meters.input:
output:SPECIFICATIONS

• Available in five sizes, with connections ranging from 250 to 630 mm.• Direct installation to the duct or viaSKKU connection box
