Rotational Viscometer

The new ROTAVISC series is capable of determining the viscosity of liquids in a wide range of applications, including quality control and the laboratory. The viscosity ranges of the four devices are distinct. The ROTAVISC provides rapid and precise results, regardless of whether the viscosity measurement is straightforward or complex. A protective bracket, temperature sensor, quick connector, hook connector, and ROTASTAND stand are all included in the scope of delivery, in addition to a standard spindle set (SP1) through SP4.input:
output:
Simple to operate

The intuitive menu guidance is facilitated by the generous 4.3 TFT display. The correct configuration of the start-up condition is also supported by a digital spirit level. The simplified ramp function simplifies repetitive tasks.input:
output:The most precise measurement accuracy

+/- 1% of the measuring range is the level of measurement accuracy of the ROTAVISC rotational viscometer for both Newtonian and non-Newtonian fluids. The reproducibility is +/- 0.2 percent.input:
output:Unsteady velocity

ROTAVISC is a viscometer that provides a stepless speed adjustment.input:
output:Viscosity measurement range

lo-vi Complete: 1 - 6.000.000 mPa

me-vi Complete: 100 - 40.000.000 mPahi-vi I Complete: 200 - 80.000.000 mPahi-vi II Complete: 800 - 320.000.000 mFalseinput:
output:Viscosity Accuracy (FSR): 1%

Viscosity Repeatability (FSR): 0.2 percent

Spring torque: 0.0673 mNm | 0.7187 mNm | 1.4374 mNm | 5.7496 mNm

Spindle series measurement: SP set-1 | SP set-2

Output motor rating: 4.8 watts

Yes, overload protection is implemented.Rotation direction: right

TFT display and speed control

Speed range: 0.01 - 200 rpm Setting accuracy speed: 0.01 ± rpmTorque display/measurement: YesTimer: YesTime setting range: 0.017 to 6000 minutesTemperature measurement resolution: 0.1 K
