Resting Electrocardiograph

A cost-effective EKG machine that is ideal for emergency responders, family practices, and hospitals.Features:Lightweight and portable design - Suitable for offices with restricted space and mobile use.Simple data input and operation - One-touch operation and an alphanumeric keyboardPower supply: AC/DC power supply with a built-in rechargeable batteryPacemaker detection - Complies with the standards of ANSI/AAMI EC11.input:
output:EKG/ECG Interpretation - Automatic measurement and interpretation for pediatrics and adultsinput:
output:
Periodic recording - Two-step exercise test with periodic recordingHeart rate variability (HRV) analysisinput:
output:Internal thermal printer and external printer for recording purposesinput:
output:Memory and data transmission - SD card and card reader, as well as a flash drive (not included).Options for data transmission to a personal computer include the use of an Ethernet or RS232 port.The internal storage has been upgraded to accommodate 200 ECGs.The Smart ECG Viewer is a PC-based data management software that allows for the export of data in XML format.SD card and card reader, flash diskinput:
output:Carrying bag and rolling standSPECIFICATIONSIn general,Input circuit: Protection against defibrillationinput:
output:Lead: The standard twelve leadsinput:
output:Acquisition mode: 12-channel simultaneous (10-24s adjustable)input:
output:A/D converter: 24 bitsinput:
output:Sampling rate: 1000Hz per channel, with a maximum of 10,000Hz for pacemaker detection.input:
output:input voltage range: ±5mVp-pinput:
output:Time constant: greater than or equal to 3.2 secondsinput:
output:Frequency response: 0.05Hz to 150Hzinput:
output:Calibration voltage: 1 mV with a tolerance of ±2%input:
output:Sensitivity: 2.5, 5, 10, 20, 10/5, AGC (mm/mV)input:
output:Input impedance: greater than 50 kiloohmsinput:
output:Current in the input circuit: less than 10 nAinput:
output:Noise level: less than 12.5 μ Vp-pPatient leakage current: < 10 μ Vp-p (220V-240V)input:
output:Auxiliary current of the patient: less than 0.1 μ A (DC)
