Refrigerated Air Dryer

The compressed air temperature is reduced by AmcareMed refrigerated dryers through the utilization of refrigerant.

At low temperatures, the water vapor in compressed air becomes supersaturated and condenses into liquid droplets. These droplets are subsequently separated from the compressed air by condensing water (including oil and dust) through an air-water separation device.Details of the Product…The AmcareMed refrigeration air dryer operates on the principles of dehumidification and freezing, and the compressed air is both hot and humid.Exchanged through the evaporator, the gaseous water in the compressed air is condensed into liquid water. This liquid water is formed through gas-water separation and is drained out of the machine through the gas-water separator.Specificationsinput:
output:Working pressure: 0.7-10 Mpa (Use scope: 0.7 Mpa-1 Mpa)

The maximum temperature at the inlet is 45℃.
Temperature range: 2℃ to 38℃

The temperature differential between the entrance and exit is 5-10℃.

Low pressure dew point: 3℃ (Atmospheric pressure dew point: -22℃)A high-efficiency aluminum plate heat exchanger unit with a small pressure drop and a good heat dissipation effect.

Compressed air is directed through components to facilitate spray treatment.

Gas-liquid separation is facilitated by a distinctive design that thoroughly processes sewage.
