Rapid Digital Test

The CE-ATP 1 is a surface testing instrument that is used for food safety and hygiene. It is also known as an ATP meter, lumitester, or luminometer. This luminometer enables the rapid and effortless testing and monitoring of first-generation adenosine triphosphate (ATP) to guarantee the appropriate sanitization, sterilization, and cleanliness. The PCE-ATP 1 is an ATP tester that is widely applicable in a variety of applications for the purpose of cleanliness control and documentation.input:
output:Fundamental operation



To obtain a sample of the surface to be tested, utilize the PCE-ATP SWAB (sold separately; refer to accessories). Push the swab all the way down into the tube to ensure that it is in contact with the reaction liquid and reagent. It is recommended that the tube be gently shaken to guarantee that the sample is completely covered. Insert the entire test tube into the measuring chamber of the PCE-ATP 1 testing device. The device display displays the measurement results in relative light units (RLUs) after 10 seconds.input:
output:KEY POINTSinput:
output:- Provides a measurement range of 0 to 999,999 relative light units (RLUs)- Internal memory stores up to 10,000 data records that are date- and time-stamped.
- Facilitates the rapid identification of microbial residues- Accurate measurement results are displayed on a large LCD screen within 10 seconds.input:
output:- Quantifies intracellular and extracellular ATP.input:
output:- Offers autocalibration and multiuser functionality.- Offers connectivity through Bluetooth and USB printer interfaces.- Comprises computer software for analysisinput:
output:DETAILS



Method of detectionUse of photodiodes for analog integrationinput:
output:Output of datainput:
output:Relative light units (RLUs)± 5 RLUs of background interferenceWidth of measurement0... 999,999 RLUsTime measurementTen secondsinput:
output:The display is as follows:3.5-inch graphic LCD
