Portable Patient Monitor

Monitoring parameters include HR, ECG, SPO2, NIBP, RESP, TEMP, and CO2.input:
output:Data storage that exceeds 1200 hoursinput:
output:Mainstream/bypass ETCO2 interface as standardLCD display with a resolution of 1280*800.

Mainstream/bypass ETCO2 interface as standardOperational interface that supports more than five languages (optional)Twenty types of arrhythmia event alarms are supported, as well as the ST segment analysis function.

The printing function is triggered, and each abnormality is recorded in real time.

High-capacity lithium battery, with a continuous operating time of at least 300 minutes.

Grid, inotropic interference, anti-defibrillation, and electric knifeinput:
output:Accessories:Five-lead heart wire*1Body surface temperature probe*1Blood oxygen probe*1One extension tube for blood pressure*Four disposable blood pressure cuffsTwenty-five disposable electrode sheets or clipsElectrocardiogram (ECG):Lead selection: standard three-/five-lead; up to seven leads can be displayed on the same screen. Ⅰ, Ⅱ, Ⅲ, AVR, AVL, AVF, V chest leads

Value detection range for electrocardiograms: 15 to 350 beats per minute

Resolution: 1 beats per minuteAccuracy of measurement: ±2% or ±2bpm, whichever is greater.Frequency response: 0.67 Hz to 40 Hz

Monitoring of the S-T segment: -2.0 mV to 2.0 mV

Electrode off indication: light and sound prompt

Scan speed: 6.25, 12.5, 25, and 50mm/sec.Gain selection: ×0.125, ×0.25, ×0.5, ×1, ×2, ×4, automatic

ECG calibration: 1mV + 5%

Protection isolation is capable of withstanding a voltage of 4000V/AC/50Hz.ECG cable lead wire: 3/5 leadA universal ECG cable with five leads and a buckle type is the standard configuration.Configuration: research-specific ECG cable cable, (custom small clip)Alarm: Alarm value upper and lower limits can be preset, with automatic memory and alarm review.Oxygen saturation:Display: Oximetry value, pulse bar graph, waveform, pulse valueOximetry range: 0%-100% for equines, canines, and felines.
