Pharmacy Refrigerator

DIN 13277 certification is currently in progress, as is IEC 60068-3 compliance.input:
output:AestheticsExterior finish: White/Steel

HIPS polystyrene is the material used to construct the inner cabinet.

Door type: Double-panel selective glass door

Self-closing door: YesDoor frame: Aluminum

Vertical metallic handleinput:
output:Product specifications in generalMaximum capacity: 130

A temperature range of +10 to +35 is considered ambient.

Relative humidity: less than 75%

Temperature range / factory temperature setting: +5

Heat output: TBC kJ/hFluctuation: 0.5°CGradient: 2.9°C

42 dB(A) relative to pW for airborne acoustical noise emissionsSizes

Internal Dimensions (H x W x D): 725 x 465 x 392 mmDimensions of the package (H x W x D) are as follows: 950 x 570 x 640 mm.Depth (open doors): 1135 mmBrutal Weight: 40 kgElectrical propertiesThe daily energy consumption is 0.75 kWh per 24 hours.

275,00 kWh of energy are consumed annually per year.

Voltage/frequency rating: 220-240 V/50 Hz

Cord length in centimeters / Type: 180 / Euro plug

Ceiling light strip: Internal lighting location

The lighting technology employed was LED.
input:
output:Equipment and technical maintenanceDynamic cooling system

R600a is the refrigerant.

Alarm contact that doesn't require voltage:Yes, protection against contact with cold surfaces is provided.Connection to an external alarm system: Yes Safety thermostat to prevent temperature below +2°C: Yes

RS485 network data transmission: YesTemperature recording and transfer via mobile application (connected via Bluetooth): YesTemperature recording and transfer via USB: False

Power supply to the controller in case of emergency: Certainly.

Alarm indicator activated in response to temperature fluctuations (remains visible until manually removed): YesExternal probe connection: Yes

The controller displays the actual temperature as the minimum and maximum: Certainly.

Safety controller: Yes
