Panoramic Radiography Flat Panel Detector

76㎛ Optimal Image Quality at a Low DoseSimple and customizableReliable image acquisition with a wide field of viewinput:
output:Image Processing Technology for Enhanced Image QualityMaximum Diagnostic Accuracy, Minimum Radiation Doseinput:
output:The EXPD 2430P is a dynamic X-ray detector of the indirect type (CsI) that is intended for integration into products by X-ray system manufacturers. The EXPD 2430P is the optimal solution for any dynamic imaging requirements due to its high performance and low noise electronics.input:
output:The EXPD 2430P generates diagnostic images that are both clear and low-noise, even at low doses, as a result of the dedicated HW and image processing technology of DRTECH.input:
output:The highest quality of images at a low doseinput:
output:- DRTECH’s Ultra Low-Noise Electronic with IGZO

– The FOCUS (Fluorescent Optical CsI Upgraded Structure) Scintillator achieves an exceptional SNR even at low doses.- >
DQE performance of 80%- Image with High Resolution and Small Pixel Sizeinput:
output:Adaptable ∙ Simple Installation- Convenient and Simple Imaging Parameter Setting

– Broad Dynamic Range

– ROI is freely adjustable in terms of size and position.- High frame rate (up to 45 frames per second)Image Acquisition with a Wide Field of View and Reliabilityinput:
output:- Increased field of view (FOV) due to a reduced SWD (Shoulder Wall Distance)- Internal memory capable of preventing image loss (up to 16GB) – Image processing technology for enhanced image qualityTRUVIEW®ART improves image sharpness and MTF by over 30%.

DEPAITM AI Denoising Technology enhances SNR by over 30% and enables low-noise imaging.
