Pachymeter

The OD1 series for ophthalmology biometry is our classic gift to doctors, the result of nearly two decades of ultrasound research. It is a single device that can realize three models of applications, despite its 5.7" color LED touch screen and sensitive and accurate measurement capabilities.input:
output: Probe Frequency: 10 MHz

Resolution: 0.01 mm Precision: ±0.1mm Adjustable gain: 0-120 dB

Velocity: 1640 m/s (measurement range: 15–35 mm)

Measurements: ACD, Lens, Vitreous, and AXL

Examination modes include normal, aphakia, dense cataract, PMMA, acrylic, and silicone.input:
output:Immersion and contact, automatic and manual, are the modes of measurement.

IOL formulas: SRK-II, SRK-T, BINKHORST, HOLLADAY, HOFFER-Q, and HAIGISinput:
output: 20 MHz is the frequency of the probe.

Resolution: 1 micrometer

Range of measurement: 0.23 to 1.3 millimeters Precision: ±5 micrometersinput:
output: Primary componentPower adaptor

Touch screen pen



10.0 MHz A probe

Gage block for A-scan/Biometer

The primary unit Angled probe with a frequency of 20.0 MHz Gage block for pachymeter Power adapter Touch screen pen Gage block for pachymeter The primary unit 10.0MHz A probe Angled probe with a frequency of 20.0 MHz There are two types of gauge blocks:br/>
and a power adaptor. Touch screen pen
