Oxygen Generator

The Arigmed Portable Personal Medical Oxygen Generator from OGSI (USA) is equipped with PSA technology (Pressure Swing Adsorption) to separate oxygen and nitrogen, thereby enabling oxygen to be used.
The system is self-contained in a wheeled cabinet, which includes the oil-free air compressor, filter system, and oxygen, and is capable of producing on-site for one person or patient with a purity level of 95%.A control system and storage tank that are intended for continuous operation.



** The specifications provided are contingent upon the following conditions: The temperature is 70°F, the relative humidity is 30%, and the sea level is rising.input:
output:
Oxygen Purity:• It is a dependable oxygen backup system that ensures a purity of 95% ± 5%, contingent upon the flow rate.input:
output:
Dew point: -60°F (-51°C).input:
output:Mounting:• The structure is composed of steel and aluminum plates, with stainless steel front and rear panels.

• White powder coating finish.input:
output:Power Source:120 volts, 60 Hz, single phase, 4.0 ampsinput:
output:Contains:• An oil-free air compressor with a HEPA filter system ensures that the air is delivered dry and free of oil.

• Air-coil for Cooper aftercooler.

• Purity filters of HEPA grade.

• OGSI (USA) PSA Oxygen Generation System.

• Mini-tank for oxygen storage.

• Pressure regulator.

• Analog pressure gauges.• Ligthing electrical switch.



• DISS CGA-V5 oxygen outlet.Equipment Not Included:

• Oxygen Humidifier
